Model 5A18

Add to Compare

ADA Compliant Wall Mount Wash Station

Constructed from welded #16 gauge type 304 stainless steel. The front, bottom and back are formed from a single sheet with a rolled rim on front and sides. Exposed surfaces have a blended uniform satin finish.

Includes:

(1) Wall mount sink – Model 5A18
(1) Strainer assembly with basket – Model 1010
(1) Wall-mounting brackets – Model 1040

Quick Specs

Outside Dimensions 30″ x 20″ x 15.5″ High
Inside Bowl Size 27″ x 16.5″ x 5″ Deep
Back Splash height 10″
Water Activation N/A
Flow Rate N/A
Inlet Connections N/A
Drain Opening 2″
Finish Polished Satin
Strainer 1-1/2″ dia. slip-joint connection
Wall Mounting Bracket 1/4″ dia. mounting holes
